Factory Series FLOAT®3 are the perfect ultra-lightweight suspension upgrade choice for riders who need to spend more time riding and less time tuning. With the infinitely adjustable air spring and custom factory-tuned damping, riders can dial in the perfect setting quickly and easily. The FLOAT 3’s Internal Floating Piston (IFP) separates the high-pressure nitrogen gas from the damping oil, making the ride consistent and fade-free. Genuine Kashima Coat and Chrome-silicon negative springs keep the stutter bumps and chatter to a minimum. Better performance plus hassle-free adjustability and reliability, equals faster rides and bigger smiles.

1. Infinitely adjustable air chamber gives a progressive spring rate and provides significant weight savings
2. Shed up to six pounds off your ATV (when replacing coil spring shocks)
3. Precision manufactured damping pistons for maximized damping consistency and flow characteristics
4. Race-proven velocity-sensitive damping control technology: Application specific tuning with different piston flow designs and variable valving specifications
5. Aerospace-grade PTFE lined spherical bearings to maximize durability
6. Anodized Internal Floating Piston (IFP) and bearing housing to prevent oil contamination and to boost seal durability and lifespan
7. 6061-T6 aluminum body caps, bodies, air sleeve.
8. Easy-access, main air spring Schrader valve
9. Fully re-buildable and infinitely adjustable main piston valve stack
10. Samurai Sealing System specifically designed from a special low-temperature, highly durable material that scrapes away mud, dirt and debris while keeping the seals lubricated for minimal friction
11. Ultra-lightweight
12. Genuine Kashima Coat
13. 6061-T6 aluminum body caps, bodies, and air sleeves
14. Chrome silicon negative spring
15. Internal Floating Piston (IFP)

Dimensions
W 8in * H 4in * L 25in
Weight: 8lbs
